| Operating voltage |
120 – 240 V AC/DC (min. 110 V, max. 265 V) |
| Heating Power |
15 W, 25 W, 30 W, 50 W, 60 W, 75 W, 100 W, 150 W. |
| Maximum allowable current |
3 A |
| Heating element |
PTC resistor - temperature limiting |
| Heater body |
extruded aluminum profile, anodized |
| Connection casing |
Plastic according to UL94 V-0, black |
| Mounting |
Clip for 35 mm DIN rail, EN 60715 |
| Fitting position |
Vertical airflow (air outlet up, connection on bottom) |
| Operating/Storage temperature |
-45°C to +70°C |
| Operating/Storage humidity |
max. 90 % RH (non-condensing) |
| Protection type / Protection class |
IP20 / I (earthed)
|
